Fuel Tank Non Ferrous

At Fabri-Tech, we do more than just provide custom fabrication solutions – we have a highly trained assembly team armed with the tools, skills, and knowledge to build turnkey products, finished and ready for your application requirements.

Built for a customer in the transportation industry, the cradle assembly shown here is used to house and secure the fuel tank in a motor coach. Working with the customer specifications, our procurement staff sourced the 304 stainless steel component parts as well as all required hardware for the assembly process. Careful attention to detail and expert workmanship enabled us to build each cradle, which featured dimensions of 687 mm in length, 712 mm in width, and 1,575 mm in height, to within precise ±1 mm tolerances. We also applied a uniform layer of undercoating to protect against rust and damage from exposure to salt and roadway grit.

The proficiency and expert skills of our assembly professionals made this project a success and we continue to deliver 40 units a month to this very satisfied customer.

To learn more about how our assembly services can streamline your next project, contact us today.

Request Quote


Product Description This product is used to house and secure a fuel tank.
Assembly Capabilities Applied/Processes Primary:
Under Coating
Component/Hardware Sourcing
Overall Part Dimensions 687 X 712 X 1575 MM
Tightest Tolerances +/- 1MM
Material Used 304 Stainless Steel
In process testing/inspection performed Visual Inspection, Dimensional Inspection
Industry for Use Motor Coach
Volume 40/Month
Delivery/Turnaround Time 4 Weeks
Delivery Location Plattsburgh, NY
Standards Met Customer Specifications, 2D CAD Drawing
Product Name Fuel Tank Cradle Assembly
